Power Distribution Bus

$35.00

Basic Features

  • Easily distribute power in a growing Euro Rack Modular Synthesizer system.

  • Connect up to 10 Modules with the 16-pin (2x8) Shrouded/Box/Keyed Headers.

  • Daisy-chain to additional bus boards with the 2 Screw-Terminal Blocks.

  • Wire/Solder Tabs to connect to CV and GATE signals.

  • Double Sided and Wide Traces, with plentiful VIAs for additional decoupling.

  • Two-Layer Ground-Plane, for low-impedance across all connectors.

  • 2x 10uF of Local Capacitor Decoupling and Filtering on each of the power rails. (+12,-12,5v)

  • Parallel Reversed-Diodes across each power rail, providing Reverse Voltage-Spike protection.

  • 6 Mounting hole options. (3.75” & 1.2” Spacing)

  • 8-inches x 1.5-inches x 0.75-inches

  • 204mm x 39mm x 19mm
